| Capacities | |
|---|---|
| Maximum turning length: | 498 mm |
| Maximum turning diameter: | 300 mm |
| Swing over bed: | 525 mm |
| Swing over carriage: | 350 mm |
| Distance between centres: | 534 mm |
| Maximum bar material diameter: | 65 mm |
| Travel | |
| X-axis: | 190 mm |
| Z-axis: | 575 mm |
| Spindle | |
| Spindle speed : | 35 to 4.000 rpm |
| Number of spindle speed ranges stepless: | Continuos |
| Spindle bore: | 76 mm |
| Second spindle | |
| Second head stroke (B-axis): | 585 mm |
| Second head positioning speed | 1.800 mm/min |
| Turret | |
| Turret type: | 12-station drum turret |
| Number of tools: | 12 |
| Turning tool shank: | 25 mm |
| Boring bar shank: | 40 mm |
| Feed rate | |
| Rapid traverse rate X, Z axes: | 3.000 mm/min |
| C-axis: | 400 rpm |
| Motors | |
| First head motor power: | 22 kW / 30 HP |
| Second head motor power: | 7,5 kW / 10 HP |
| Rotary tools spindle motor power: | 3,7 kW / 5 HP |
| Coolant pump motor: | 0,18 kW / 0,2 HP |
| Other specifications | |
| Cool tank capacity: | 160 l |
| Approximate dimensions: | 3.050 x 1.700 x 1.950 mm |
| Approximate weight: | 4.600 kg |
Características basadas según ficha técnica.
